Precision Alignment Services

Precision Alignment Services

Advantages
  • Team of Specialists
  • Higher Accuracy
  • Reduced Measurement Time
  • Lower Cost
  • Convenience of Digital Data
  • Lifecycle Quality Control
Request for Info or Quote Datasheet

Precision Alignment Services by NSI-MI Technologies is the ultimate solution for precise measurements, engineering expertise, and detailed reports tailored to meet your specific needs. Our cutting-edge laser tracker system guarantees accuracy and precision traceable to NIST standards, providing confidence in the measurement accuracy of high-frequency antennas. With a speed and accuracy capabilities of up to 1000 measurements per second, our services eliminate the need for manual laborious measurements.

Our expert team will handle your precision alignment services efficiently and effectively, reducing the requirement for additional test personnel. By utilizing our permanent monuments that track drift and misalignment over time, you can ensure optimal performance of your equipment. Trust NSI-MI to enhance your measurement quality assurance program with advanced technologies that deliver faster results at a more affordable price.

Experience the NSI-MI Difference and discover how precision alignment can be faster, more accurate, and cost-effective compared to traditional methods. Let our team adapt our processes to suit your unique applications and range configurations, ensuring peak performance every time. From on-site scanner Z plane mapping to maintenance services, we have you covered for all your alignment needs.


Planar scanner z-planarity before correction Planar scanner z-planarity after correction

We offer a comprehensive range of Precision Alignment services to ensure accurate alignment of all components within test ranges. Our expert team can determine center of rotation, normal axis to a plane of rotation, and characterize and correct for axis alignment accuracy. We establish permanent coordinate systems to measure repeatability and drift, verify high-frequency measurements, and comply with government performance specifications. Say goodbye to laborious manual measurements and trust precise results every time with our Precision Alignment Services.

Range Axis Alignment

Align the range axes in for compact ranges, reflectors, and radomes to ensure accurate measurements and reliable performance.

Positioner Axis Alignment

Determine the center of rotation of a positioner axis and establish the normal axis to a plane of rotation for precise positioning and alignment.

Alignment Accuracy Correction

Characterize and correct for positioner axis alignment accuracy to ensure consistency and accuracy in measurements.

Coordinate System Establishment

Establish a permanent coordinate system to measure repeatability and drift of surfaces, axes, and coordinate systems for reliable and consistent results.

Range Performance Verification

Verify that your range can perform higher-frequency measurements under consideration and comply with government range performance specifications for quality assurance.

Reflector Surface Characterization

Characterize reflector surface accuracy to ensure optimal performance and accuracy in measurements.

Expert Services

Benefit from the expertise and experience of our professional staff in providing high-quality alignment services for range equipment.
